Function

Indicator Light

1 × green pairing indicator

12 × alarm LED groups

Button

1 × power switch

Buzzer

1 × buzzer

Remote Update

Cloud update

Low Battery Detection

Yes

Battery Level Display

Yes

Tamper

Yes

Signal Strength

Signal strength detection

Wireless

Carrier Frequency

433.1 MHz–434.6 MHz

Transmitter Power (EIRP)

Limit 10 mW

Communication Distance

Up to 1,200 m (3,937.01 ft) in an open space

Communication Mechanism

Two-way

Frequency Hopping

Yes

Encryption Mode

AES128

General

Power Supply Mode

4 × CR123A battery/9–15 VDC

Battery Model

CR123A

Battery Life

4 CR123A batteries can be used for 3.4 years (if triggered fortnightly and the alarm sounds for 120 s each time with a battery efficiency of 80%)

Operating Temperature

–25 °C to + 60 °C (–13 °F to + 140 °F)

Operating Humidity

10%–90% (RH)

Product Dimensions

200 mm × 200 mm × 52.5 mm (7.87″ × 7.87″ × 2.07″) (L × W × H)

Packaging Dimensions

255 mm × 239 mm × 64 mm (10.04″ × 9.41″ × 2.52″) (L × W × H)

Net Weight

610 g (1.34 lb)

Gross Weight

920 g (2.03 lb)

Installation

Wall mount

Casing

PC + ABS

Protection

IP65

Certifications

CE; FCC

Technical

Scenario

Outdoor

Operating Current

Max 1.4 A, 92 uA (standby), battery 3 V

Max 1 A, 7.3 mA (standby), 12 VDC

Sound and Light Alarm

Light alarm and multiple alarm sounds, including fire, medical, intrusion, panic, and more.

Sound Pressure

Maximum: 110 dB(A) at 1 meter

Minimum: 95.2 dB(A) at 1 meter
